产品名称：英制蜗轮减速机 | |
| 产品介绍： 浏览次数：次 |
||
产品简介：
|
NEMA Frame |
LA |
LB |
LC |
LE |
LZ |
Input | |
|
Bore |
Keyway | ||||||
|
56C |
5.875 |
4.50 |
6.50 |
0.16 |
0.43 |
0.625 |
3/16×3/32 |
|
143TC/145TC |
5.875 |
4.50 |
6.50 |
0.16 |
0.43 |
0.875 |
3/16×3/32 |
|
182TC/184TC |
7.250 |
8.50 |
9.00 |
0.23 |
0.55 |
1.125 |
1/4×1/8 |
|
213TC/215TC |
7.250 |
8.50 |
9.00 |
0.23 |
0.55 |
1.375 |
5/16×5/32 |
|
254TC/256TC |
7.250 |
8.50 |
10.00 |
0.23 |
0.55 |
1.625 |
3/8×3/16 |
|
Size |
Radio |
A |
A1 |
AB |
AC |
B |
BB |
BD |
|
40 |
5：1 |
2.58 |
3.92 |
3.94 |
1.85 |
3.31 |
2.68 | |
|
50 |
2.85 |
4.19 |
4.48 |
2.08 |
3.82 |
2.72 | ||
|
60 |
3.15 |
4.43 |
5.00 |
2.20 |
4.33 |
2.99 | ||
|
63 |
3.37 |
4.67 |
5.51 |
2.36 |
4.45 |
3.46 | ||
|
70 |
3.76 |
4.63 |
6.10 |
2.52 |
5.12 |
3.31 | ||
|
80 |
4.11 |
5.84 |
6.69 |
2.85 |
5.51 |
3.94 | ||
|
100 |
4.78 |
6.51 |
8.03 |
3.33 |
6.42 |
4.49 | ||
|
120 |
6.10 |
8.26 |
7.48 |
10.24 |
3.94 |
7.28 |
5.04 | |
|
135 |
6.89 |
9.06 |
8.32 |
11.65 |
4.33 |
8.27 |
5.91 | |
|
155 |
7.64 |
10.24 |
9.35 |
12.99 |
5.20 |
9.92 |
6.69 | |
|
175 |
8.78 |
11.42 |
11.02 |
14.57 |
5.71 |
10.31 |
7.32 |
|
Size |
BE |
BF |
CC |
H |
HL |
LL |
Z |
L |
|
40 |
2.13 |
3.15 |
1.575 |
5.00 |
1.34 |
2.09 |
5/16-18 |
0.63 |
|
50 |
1.97 |
3.54 |
1.969 |
5.91 |
1.38 |
2.56 |
5/16-18 |
0.63 |
|
60 |
2.13 |
3.94 |
2.362 |
6.97 |
1.65 |
2.95 |
3/8-16 |
0.75 |
|
63 |
2.69 |
4.87 |
2.480 |
7.32 |
1.89 |
2.95 |
3/8-16 |
0.75 |
|
70 |
2.56 |
4.92 |
2.756 |
8.46 |
2.16 |
3.54 |
3/8-16 |
0.75 |
|
80 |
2.76 |
5.51 |
3.150 |
9.84 |
2.56 |
4.13 |
3/8-16 |
0.75 |
|
100 |
3.54 |
7.09 |
3.937 |
12.20 |
3.15 |
5.12 |
1/2-13 |
0.94 |
|
120 |
3.94 |
8.66 |
4.724 |
14.57 |
3.74 |
6.10 |
1/2-13 |
0.94 |
|
135 |
4.33 |
10.24 |
5.315 |
16.73 |
4.13 |
7.28 |
5/8-11 |
1.13 |
|
155 |
4.72 |
11.02 |
6.102 |
18.15 |
4.05 |
7.99 |
5/8-11 |
1.13 |
|
175 |
5.51 |
12.60 |
6.890 |
20.51 |
4.84 |
8.78 |
3/4-10 |
1.38 |
|
Size |
Output Shaft |
With Horizontal Base |
NEMA Frame | |||||||
|
S |
LS |
W×Y |
E |
F |
M |
N |
G |
X | ||
|
40 |
0.625 |
1.38 |
3/16×3/32 |
3.54 |
3.94 |
4.33 |
4.92 |
0.51 |
0.39 |
56C |
|
50 |
0.750 |
1.57 |
3/16×3/32 |
3.74 |
4.33 |
4.72 |
5.51 |
0.59 |
0.43 |
56C、140TC |
|
60 |
1.000 |
1.97 |
1/4×1/8 |
4.13 |
4.72 |
5.12 |
5.91 |
0.71 |
0.43 |
56C、140TC |
|
63 |
1.000 |
1.97 |
1/4×1/8 |
4.33 |
5.91 |
5.51 |
7.09 |
0.71 |
0.43 |
56C、140TC |
|
70 |
1.125 |
2.36 |
1/4×1/8 |
4.53 |
5.91 |
5.91 |
7.48 |
0.71 |
0.59 |
56C、140TC |
|
80 |
1.375 |
2.56 |
5/16 5/32 |
5.31 |
7.09 |
6.69 |
8.66 |
0.71 |
0.59 |
56C、140TC、180TC |
|
100 |
1.500 |
2.95 |
3/8×3/16 |
6.10 |
8.66 |
7.48 |
10.63 |
0.79 |
0.59 |
56C、140TC、180TC |
|
120 |
1.750 |
3.35 |
3/8×3/16 |
7.09 |
10.24 |
9.06 |
12.60 |
0.98 |
0.71 |
180TC、210TC |
|
135 |
2.250 |
3.74 |
1/2×1/4 |
7.87 |
11.42 |
9.84 |
13.78 |
1.18 |
0.71 |
180TC、210TC |
|
155 |
2.500 |
4.33 |
5/8×5/16 |
8.66 |
12.60 |
11.02 |
14.96 |
1.26 |
0.79 |
180TC、210TC |
|
175 |
2.750 |
4.33 |
5/8 5/16 |
9.84 |
13.78 |
12.20 |
16.14 |
1.46 |
0.79 |
180TC、210TC、250TC |
